10
Remote Manual Operation - Wiring Diagram
Position actuator using contact closure
Ground to green
screw in floor
of housing
G
N
L
1 2 TB2
120/240 AC Input
240AC 120AC
Manual Increase
Manual Decrease
TB1
1
2
3
4
5
6
7
8
9
10 1
2
3
4
5
6
7
8
9
10
TB3
1. DO NOT POWER MANUAL INPUTS!
2. Use unpowered mechnaical or solid state relays.
1 2 3 4 5 6 7 8 9 10 11 12
TB4
Enable Manual
Enable Manual common
3. Use external jumper across terminal 9 and 10.
!
