Cla-Val 393-01/3693-01 - Manual (Page 29)

7
TB4
1 2 3 4 5 6 7
2 1
9 10 11 12
TB2
Isolated 4-20 mA Tramsmitter -
Isolated 4-20 mA Tramsmitter +
1
2
3
4
5
6
7
10
8
9
8
TB3
1
2
3
4
5
6
7
10
9
8
TB1
Remote Setpoint
Loop Isolator
+
_
Power Supply
Load +
_
Process Variable
240AC 120AC
120/240 AC Input
+
Isolated + 24 VDC
4 to 20 ma PV input +
4 to 20 ma PV input -
Isolated common
1. Remote setpoint must be isolated and powered from external source
2. PV retransmission requires an external power supply within 12 to 36 VDC .
Maximum load = (Power supply VDC 8 VDC) / .020 A.
3. A switch may be placed between terminals 9 and 10 on TB3 to interrupt actuator
travel. Contact between 9 and 10 will stop actuator movement.
DO NOT POWER.
Optional external
switch to stop
actuator rotation
G
N
L
!
Ground to green
screw in floor
of housing
Remote Automatic Mode
Using external PV and internal
power supply to power 4-20 mA loop
