Example Programming Sequences
Set the Button Override Mode to Enabled (from factory default):

Press & Hold [LED blinks rapidly indicating unit is in Programming Mode]  Release the Button  Press 1x to change Function 1 [LED blinks 4x]  Press 1x to

change from Button Override Disabled to Button Override Disabled [LED blinks 5x to indicate the new setting is Button Override Enabled] Press & Hold [LED

blinks rapidly]  Release the Button  Press 1x to confirm Function 1 was changed [LED Blinks 2x to indicate the new setting was stored successfully]

Set the RDM Personality to 2 DMX Slots Logarithmic (from factory default):

Press & Hold [LED blinks rapidly indicating unit is in Programming Mode]  Release the Button  Press 3x to change Function 3 [LED blinks 1x to indicate the

current setting is 1 DMX Slot for Linear Dimming]  Press 4x [LED blinks 4x to indicate the new setting is 2 DMX slots Logarithmic Dimming] Press & Hold [LED

blinks rapidly]  Release the Button  Press 3x to confirm Function 3 was changed [LED Blinks 2x to indicate the new setting was stored successfully]

Set the DMX Signal Loss Behavior to Hold Last for 1 minute then fade to 100% (from factory default):

Press & Hold [LED blinks rapidly indicating the unit is in Programming Mode]  Release the Button  Press 4x to change Function 4 [LED blinks 1x to indicate

Hold Last Forever is selected]  Press 5x [LED blinks 5x to indicate Hold Last for 1 minute then fade to 100% is selected] Press & Hold [LED blinks rapidly] 

Release the Button  Press 4x to confirm Function 4 was changed [LED Blinks 2x to indicate the new setting was stored successfully]

Set the DMX Address to 123 (from factory default):

Press & Hold [LED blinks rapidly]  Release the Button  Press 2x to change Function 2 [LED blinks 10x indicating the hundreds digit is currently 0]  Press 1x

to set the hundreds digit to 1  Pause 3 seconds [LED blinks 1x to verify 1 is entered for the hundreds digit]  Press 2x to set the tens digit to 2 Pause 3

seconds [LED blinks 2x to confirm the tens digit is set to 2]  Press 3x to set the ones digit to 3 Pause 3 seconds [LED blinks 3x to confirm the ones digit is set

to 3] Press & Hold [LED blinks rapidly]  Release the Button  Press 2x to confirm Function 2 was changed[LED Blinks 2x to indicate the new setting was

stored successfully]

Set the DMX Address to 321 (from Address 123):

Press & Hold [LED blinks rapidly]  Release the Button  Press 2x to change Function 2 [LED blinks 1x indicating the hundreds digit is currently 1]  Press 3x to

set the hundreds digit to 3  Pause 3 seconds [LED blinks 3x to verify the hundreds digit is set to 3]  Press 2x to set the tens digit to 2  Pause 3 seconds [LED

blinks 2x to verify the tens digit is set to 2]  Press 1x to set the ones digit to 1  Pause 3 seconds [LED blinks 1x to verify the ones digit is set to 1] Press &

Hold [LED blinks rapidly]  Release the Button  Press 2x to confirm Function 2 was changed [LED Blinks 2x to indicate the new setting was stored successfully]
