Detailed Function Programming Table (Default show in bold)
Function Name Indicator Function Settings Available How to Modify
1 Button
Mode
4 Blinks = override disabled
5 Blinks = override enabled
Override Enabled
Override Disabled
When Function 1 is selected, observe the LED
blink sequence, to change the mode press the
button, then count the blink sequence to verify
the blink count is either 4 for disabled or 5 for
enabled, waits 3 seconds then repeats
2 Set
DMX
Address
LED blinks each digit of the current DMX
address. (Digits will blink twice per second)
Blink 1 st digit, 1 second pause, blink 2 nd digit,
1 second pause, blink 3 rd digit, 1 second
pause. Repeat. If the Address digit is zero, it
blinks 10 times. The new address is set by
pressing desired digit change during the
flashing of that digit.
Address range is 1 – 512
Default is 001
(10 blinks. Pause
10 blinks. Pause
1 blink. Pause)
If changing the hundred digit from “0” to “2”,
while the HPEPP is flashing 10 times (zero), press
the button twice. Once done entering the first
digit (most significant digit) do not press the
button for 3 seconds. The unit will then confirm
the first digit by blinking the LED twice. Next,
enter the second digit the same way as the first
while the second digit is flashing (if applicable),
then the third digit (if applicable) Once all digits
are entered, press and hold the button to exit
programming mode and confirm the changes.
(See step 5 above).
3 RDM
Personality
1 Blink = 1 DMX slot Linear
2 Blinks = 2 DMX slots Linear
3 Blinks = 1 DMX slot Logarithmic
4 Blinks = 2 DMX slots Logarithmic
5 Blinks = 2 DMX slots Linear dim | relay
6 Blinks = 2 DMX slots Logarithmic dim | relay
1 or 2 channel DMX
assignments with
logarithmic or linear
dimming curves. Also
supports dim outputs with
separate relay control, Slot
1 for intensity, Slot 2 for
relay
When Function 3 is selected the LED blinks the
current RDM personality then waits 3 seconds and
repeats. Press the button 1 to 6 times to select
the preferred Personality
4 DMX Signal
Loss
Behavior
1 Blink = Hold last Forever
2 Blinks = Fade to off over 1 second
3 Blinks = Hold last for 1 min, fade off
4 Blinks = Fade to 100% over 1 second
5 Blinks = Hold last for 1 min, fade to 100%
How the HPEPP operates
upon loss of regular DMX
update signals
When Function 4 is selected the LED blinks the
current Signal Loss Behavior then waits 3 seconds
and repeats. Press the button 1 to 5 times to
select the preferred behavior
