Extron TP Transmitters • Specifications, Accessories, and Part Numbers Extron TP Transmitters • Specifications, Accessories, and Part Numbers
Specifications, Accessories, and Part Numbers, cont’d
A-7 A-6
Accessories
Accessory Part number
P/S 150 Multiple output 15V power supply 60-432-01
Extron 9.5" Deep 1U Rack Shelf kit (RSU 129) 60-190-01
Extron 9.5" Deep 1U Basic Rack Shelf (RSB 129) 60-604-02
Extron TP Rack Mounting Kit (RSM 100) 70-123-01
Extron Under Desk Mounting Kit (MBU 125) 70-077-01
Extron Through-desk Mounting Kit (MBD 129) 70-077-02
4-gang “J” box 2.5" (6.4 cm) deep 980097
Cables and Adapters
Skew-Free™ A/V UTP cables are not recommended for
Ethernet/LAN applications.
Skew-Free™ A/V cable Part number
UTP 23SF-4/3 — 3' (90 cm) 26-569-01
UTP 23SF-4/6 — 6' (1.8 cm) 26-569-02
UTP 23SF-4/12 — 12' (3.6 m) 26-569-03
UTP 23SF-4/25 — 25' (7.6 m) 26-569-04
UTP 23SF-4/35 — 35' (10.6 m) 26-569-05
UTP 23SF-4/50 — 50' (15.2 m) 26-569-06
UTP 23SF-4/75 — 75' (22.8 m) 26-569-07
UTP 23SF-4/100 — 100' (30.4 m) 26-569-08
UTP23SF-4P/25 — 25' (7.6 m) plenum 26-570-04
UTP23SF-4P/35 — 35' (10.6 m) plenum 26-570-05
UTP23SF-4P/50 — 50' (15.2 m) plenum 26-570-06
UTP23SF-4P/75 — 75' (22.8 m) plenum 26-570-07
UTP23SF-4P/100 — 100' (30.4 m) plenum 26-570-08
UTP23SF-4P/150 — 150'(45.7 m) plenum 26-570-09
UTP23SF-4P/200 — 200' (61 m) plenum 26-570-10
UTP23SF-4P/250 — 250' (76.2 m) plenum 26-570-11
UTP23SF-4P/300 — 300' (91.4 m) plenum 26-570-12
Included Parts
These items are included in each order for a specific TP
transmitter:
Included parts Replacement part number
TP T 15HD A 60-345-02
TP Transmitters Family User’s Guide
Single output external power supply, 15 V, 0.8 A 70-057-01
Captive screw connector, 3 pole, 3.5 mm 10-265-03
TP T 15HD AV 60-346-03
TP Transmitters Family User’s Guide
Single output external power supply, 15 V, 0.8 A 70-057-01
Captive screw connector, 3 pole, 3.5 mm 10-265-03
TP T 468
TP T 468 (gray) 60-434-01
TP T 468 (black) 60-434-02
TP T 468 (white) 60-434-03
TP T 468 (EC) 60-434-10
TP Transmitters Family User’s Guide 68-546-03
Single output external power supply, 15 V, 0.8 A 70-057-01
4-gang mud ring (gray, black, white) 70-086-03, -13, -23
TP T BNC DA4 60-349-02
TP Transmitters Family User’s Guide
Single output external power supply, 15 V, 0.8 A 70-057-01
Captive screw connector, 3 pole, 3.5 mm 10-265-03
The TP T 15HD AV is a redesigned transmitter. The
audio portion of the composite video TP link can be
configured to work with the similarly redesigned
TP R BNC AV receiver or with older, unmodified
receivers. See “Audio jumpers” in chapter 2,
“Installation and Operation.” Redesigned transmitters
and receivers have an identifying label.
