Extron TP Transmitters • Specifications, Accessories, and Part Numbers
Extron TP Transmitters • Specifications, Accessories, and Part Numbers
Specifications, Accessories, and Part Numbers, cont’d
A-5
Regulatory compliances
Safety ................................. CE, C-tick, CUL, UL
EMI/EMC ......................... CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
All nominal levels are at ± 10%.
Rack mount
TP T 15 HD A,
TP T 15HD AV,
TP T BNC DA4 ................. Yes, with optional TP rack shelf mounting
kit, part #70-123-01 (RSM 100) and the 1U,
9.5" deep rack shelf, part #60-190-01
(RSU 129) or 60-604-02 (RSB 129)
Also furniture mountable with optional
under-desk mounting kit, part #70-077-01
(MBU 125) or through-desk mounting kit,
part #70-077-02 (MBD 129)
TP T 468 ............................. No, but wall or furniture mountable in a
wall box
TP T 468 EC ...................... No, but wall or furniture mountable in a
Euro Channel raceway
Enclosure type .............................. Metal
Enclosure dimensions
TP T 15HD A,
TP T 15HD AV,
TP T BNC DA4 ................. 1.3" H x 6.8" W x 4.5" D
(<1U high,
(Depth excludes connectors.)
TP T 468
Plate ............................... 4.5" H x 8.3" W (4-gang)
(11.4 cm H x 21.2 cm W)
Transmitter enclosure . 2.6" H x 3.1" W x 1.1" D
(6.6 cm H x 7.9 cm W x 2.8 cm D)
(Depth excludes front and rear panel
connectors and controls.)
TP T 468 EC
Plate ............................... 3.2" H x 7.7" W (8.0 cm H x 19.5 cm W)
Transmitter enclosure . 2.5" H x 3.7" W x 1.75" D
(6.4 cm H x 9.4 cm W x 4.5 cm D
(Depth excludes front and rear panel
connectors and controls.)
Product weight
TP T 15HD A, TP T 15HD AV 0.8 lbs (0.4 kg)
TP T BNC DA4 .................. 0.9 lbs (0.4 kg)
TP T 468, TP T 468 EC ..... 0.7 lbs (0.3 kg)
Shipping weight ........................... 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton
(International Safe Transit Association)
