Page 35
Command
ASCII (Telnet)
(host to switcher)
Response
(switcher to host)
Additional Description
Query updated
firmware
version
4Q
X12)
]
Use this command to find out which
version of firmware has been uploaded
into the processor post‑factory.
Example:
4Q
Ver04*1.00
In this example, firmware version is 1.00.
Information requests
Request switcher part
number
N
60-1235-01
]
Show switcher part number.
Verbose response
Pno
60-1235-01
]
Request AV input
number
I
Vid
X!
•Aud
X!]
Show current active video and audio
inputs.
Request model name
1I
PVS 405D
Show device name
Verbose response
Inf01*PVS 405D
]
Request model
description
2I
PoleVault Digital
Switcher
Show device description
Verbose response
Inf02*PoleVault
Digital Switcher
]
Read hardware
address (MAC)
E
CH
}
X10$]
X10$
= hardware media access control
(MAC) address (xx-xx-xx-xx-xx-xx).
Verbose response
Iph•xx-xx-xx-xx-xx-
xx
]
Set verbose mode
24
EX11)
CV
}
Vrb
X11)]
Set verbose mode.
Read verbose mode
E
CV
}
X11)]
Verbose response
Vrb
X11)]
Set unit name
EX11*
CN
}
Ipn•
X11*]
Set the unit name. (
X11*
up to 24
alphanumeric characters). Special
characters (spaces or blanks) not allowed.
Set unit name to
factory default
E
•CN
}
Ipn•
X10)]
Set the unit name back to default. Default
name
X10)
is a combination of model
name and last 3 hex pairs of MAC address
(for example PVS‑405D‑06‑DE‑2E).
View unit name
E
CN
}
X11*]
View the current unit name (
X11*
).
Reset (Zap) command
Reset all device settings
to factory
E
ZXXX
}
Zpx
]
E
ZXXX command resets all video and
audio settings
NOTE:
X!
= Video and audio input selection, 1‑5
X10)
= Default name: combination of model name and last 3 hex pairs of MAC address (for example PVS‑405D‑06‑DE‑2E).
X10$ = Hardware (MAC) address: (00‑05‑A6‑xx‑xx‑xx)
X11) = Verbose/Response mode, (default = 0 for telnet connections, 1 for RS‑232 and USB host control). 0 = Clear/none,
1= Verbose mode, 2 = Tagged responses for queries, 3 = Verbose mode and tagged responses for queries.
X11*
= Unit name is a text string up to 24 characters drawn from the alphabet (A‑Z), digits (0‑9), minus sign/hyphen (‑).
No blank or space characters are permitted as part of a name. No distinction is made between upper and lower case. The
first character must be an alpha character. The last character must not be a minus sign/hyphen.
X12)
= Firmware Query (‘Q’ commands)
*Q = Firmware and build number [
0Q = Verbose version information [<2Q> ‑ <3Q> ‑ < 4Q>] sum of responses from 2Q‑3Q‑4Q.
1Q = Firmware version [
2Q = Final stage bootloader (Uboot) version [
3Q = Factory base code version [
4Q = Updated firmware version [
PVS 405D • SIS Communication and Control
29
