Command
ASCII Command
(host to switcher)
Response
(switcher to host)
Additional Description
Input audio gain and attenuation
NOTE: The VoiceLift and Aux input audio are independent and not affected by the output volume.
Set specific input
gain/attenuation
X@
*X3%G
InX@•AudX3%]
Set gain/attenuation on specified input
X@
to
X3%
dB.
Increment specific
input gain
X@
+G
InX@•AudX3%]
Increment specific input
X@
audio level
(up).
Decrement specific
input gain
X@
-G
InX@•AudX3%]
Decrement sepcific input
X@
audio level
(down).
View specific input
gain
X@
G
X3%]
View specific input
X@
audio level.
Verbose response
InX@•AudX3%]
View current input
gain
G
X3%]
View current input audio level.
Verbose response
InX@•AudX3%]
Output volume
Set specific volume
X3#
V
VolX3#]
Set volume to
X3#
.
Increment
+V
VolX3#]
Increase volume.
Decrement
-V
VolX3#]
Decrease volume.
View volume
V
X3#]
View current volume setting.
Verbose response
VolX3#]
Front panel security lockout (Executive Mode)
Enable Executive
1X
Exe1
]
Lock entire front panel.
Disable Executive
mode
0X
Exe0
]
Unlock front panel controls. All front
panel adjustments can be made
(default).
View Executive
mode status
X
X3@]
View the current status:
0 = off [default], 1 = on
Verbose response
ExeX3@]
Pass-through mode (dedicated VoiceLift port)
Configure pass‑
through mode
E
1CD}
Cpn1]
Set VoiceLift port to pass‑through mode.
Terminate pass‑
through mode
E
0CD}
Cpn0]
Stop pass‑through mode (default).
View pass‑through
mode
E
CD}
X2&]
View pass‑through mode
Verbose response
CpnX2&]
NOTE:
X@
= Audio input number: 1 through 5, 7 (VoiceLift), 8 (Aux)
X2&
= Pass‑through mode:
0 = Not in pass‑through mode (default)
1 = In pass‑through mode
X3@
= On/Off: 0 = off/disable, 1 = on/enable
X3#
= Audio output volume: 000 to 100 (‑100dB to 0dB, in 1 dB steps), default 80
X3%
= Input audio gain and attenuation: ‑18 to +24 dB V, in 1 dB steps
Inputs 1‑5 and 8; default is 0 dB
Input 7 (VoiceLift); default is ‑3 dB
