Specifications
Video
Gain ................................................ Unity
Bandwidth ..................................... 300 MHz @ -3 dB
Video input
Number/signal type ..................... 1 analog RGBHV, RGBS, RGsB, RsGsBs
N Not compatible with interlaced signals.
Connectors .................................... 5 BNC female
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Horizontal frequency .................... 24 kHz to 130 kHz
Vertical frequency .......................... 40 Hz to 120 Hz
Nominal maximum return loss .. <-30 dB @ 5 MHz
Maximum allowed DC offset ..... 4.0 V
Input coupling ............................... AC
Video output
Number/signal type ..................... 2 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors .................................... 5 BNC female and (1) 15-pin HD female
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ 0.3 V to 1.5 Vp-p with no offset
(follows input)
Impedance ..................................... 75 ohms
Nominal maximum return loss .. -30 dB @ 5 MHz
DC offset ........................................ ±5 mV maximum with no input signal and
at 0 offset
Sync
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................... RGBHV, RGBS, RGsB, RsGsBs
(switch selectable)
Input level ..................................... Sync on R/G/B (RGsB, RsGsBs): 0.15 to
0.6 Vp-p TTL 2.0 V to 5.5 Vp-p with
±0.2 VDC offset max.
Output level .................................. Sync on R/G/B (RGsB, RsGsBs): 0.3 Vp-p
TTL 5.0 Vp-p unterminated
Input impedance .......................... 510 ohms or 10k ohms, selectable
Output impedance ....................... 75 ohms
SCS 300 • Reference Material
Reference Material
A-2
