SCS 300 • Installation, Connection, and Settings
Use 2 mounting holes on
opposite corners.
(2) 4-40 x 3/16"
Screws
9.5" Deep Universal Rack Shelf
Both front false faceplates
use 2 screws.
1/4 Rack Width Front False
Faceplate
1/2 Rack Width Front False
Faceplate
Figure 2-1 — Mounting the SCS 300 on a standard
9.5" deep rack shelf
Use 2 mounting holes
on opposite corners.
1/2 Rack Width False Front
Face Plate
(2) 4-40 x 3/16"
Screws
6" Deep Rack Shelf
1/4 Rack Width False Front
Face Plate
Figure 2-2 — Mounting the SCS 300 on a 1U 6" deep
rack shelf
4
.
If the shelf is not already mounted in the rack, use the
supplied hardware to mount it, following the instructions
that came with the shelf.
5
.
When mounted, continue the installation by connecting the
input, output, and power cables.
