Configure port, Timeout sis command, Must be in verbose mode 1 or 3 (see the – Extron Electronics MTPX Plus 6400 Series Setup Guide User Manual
Page 21: Set verbose mode sis, Command

NOTE:
X2^
= IP address nnn.nnn.nnn.nnn
X2&
= DHCP
0 = off, 1 = on
X2*
= Verbose mode
0 = clear or none (default for Telnet connection)
1 = verbose mode (default for RS-232/RS-422 connection)
2 = tagged responses for queries
3 = verbose mode and tagged for queries
X2(
= Port timeout interval
1 (= 10 seconds) – 65000 (default is 30 = 300 seconds = 5 minutes)
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
IP setup
Set IP address
EX2^
CI
}
Ipi
X2^]
Read IP address
E
CI
}
X2^]
Set subnet mask
EX2^
CS
}
Ips
X2^]
Read subnet mask
E
CS
}
X2^]
Set gateway IP address
EX2^
CG
}
Ipg
X2^]
Read gateway IP address
E
CG
}
X2^]
Set DHCP on or off
EX2&
DH
}
Idh
X2&]
Read DHCP on/off status
E
DH
}
X2&]
Set verbose mode
EX2*
CV
}
Vrb
X2*]
Read verbose mode
E
CV
}
X2*]
Configure current port timeout
E
0*
X2(
TC
}
Pti0*
X2(]
Read current port timeout
E
0TC
}
X2(]
Configure global IP port timeout
E
1*
X2(
TC
}
Pti1*
X2(]
Read global IP port timeout
E
1TC
}
X2(]
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Lock (Executive) modes
NOTE: See "
Setting the front panel locks (executive modes)
" on page 15 for more information on the Lock modes.
Lock all front panel functions
1X
Exe1
]
Enable Lock mode 1.
Lock advanced front panel
functions
2X
Exe2
]
Enable Lock mode 2.
Unlock all front panel
functions
0X
Exe0
]
Enable Lock mode 0.
View lock status
X
X2!]
Information requests
Information request
I
V
X2@
X
X2#
•
A
X2@
X
X2#]
In the response:
V
X2@
X
X2#
is the video matrix size.
A
X2@
X
X2#
is the audio matrix size.
Request part number
N
X2$]
See the MTPX Plus 6400 Series User Guide for
part numbers.
Query controller firmware
version
Q
X2%]
Example:
Q
1.23
]
The factory-installed controller firmware
version is 1.23 (sample value only).
NOTE:
X2!
= Lock mode
0, 1, or 2
X2@
= Inputs
Total number of inputs for this switcher
X2#
= Outputs
Total number of outputs for this switcher
X2$
= Part number
X2%
= Firmware version number to second decimal place (x.xx)
