Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Output skew adjustment
Set all output skew
adjustment values
EX@
*
X*
*
X*
*
X*
Oseq
}
Set a specific skew adjustment for the TP
output.
X*
values are listed in RGB order.
Oseq
X@
*
X*
red
*
X*
green
*
X*
blue
]
Example:
E
2*0*0*4Oseq
}
Oseq02*0*0*4
]
Set the skew settings for output 2 as follows:
Red = 0 ns
Green = 0 ns
Blue = 8 ns (4 x 2 ns)
Increment one output skew
adjustment value
EX@
*
X(
+Oseq
}
Increase the
X(
skew plane adjustment for
output
X@
by 1 step (2 ns).
Oseq
X@
*
X*
red
*
X*
green
*
X*
blue
]
Example:
E2*2*+Oseq
}
Oseq02*0*0*5
]
Increase the blue skew output for output 2 by
2 ns (from 8 ns to 10 ns).
Decrement one output skew
adjustment value
EX@
*
X(
-Oseq
}
Decrease the
X(
skew plane adjustment for
output
X@
by 1 step (2 ns).
Oseq
X@
*
X*
red
*
X*
green
*
X*
blue
]
Read output skew adjustment
values
EX@
Oseq
}
X*
red
*
X*
green
*
X*
blue
]
Output pre-peaking
Set output pre-peaking on
EX@
*1Opek
}
Opek
X@
*1
]
Pre-peak the TP output.
Set output pre-peaking off
EX@
*0Opek
}
Opek
X@
*0
]
Do not pre-peak the TP output.
Read output pre-peaking
setting
EX@
Opek
}
X1!]
NOTE:
X@
= Output number
01 – maximum number of outputs for your configuration
X*
= Skew adjustment range
00 – 31 (each step = 2 ns)
X(
= Video plane
0 = red
1 = green
2 = blue
X1!
= Pre-peaking status
0 = off, 1 = on
NOTE:
X@
= Output number
01 – maximum number of outputs for your configuration
X#
= Mute
0 = off (unmuted)
1 = on (muted)
X1@
= Local video output number
01 – 04
X1#
= Local output sync polarity
0 = H– /+ (default)
1 = H+ / V–
2 = H– / V+
3 = H+ / V+
4 = No sync stripping
X1$
= Audio or RS-232 mute
0 = no mute
2 = audio or RS-232 is muted
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Local video output sync polarity
Set local output polarity
EX1@
*
X1#
Opol
}
Opol
X1@
*
X1#]
Set the horizontal and vertical sync polarity
for local output
X1@
.
Example:
E
2*0Opol
}
Opol2*00
]
Set local output 2 to output negative
horizontal and vertical sync.
Read local output sync settings
EX1@
Opol
}
X1#]
Audio or RS-232 mute commands
Audio or RS-232 mute
X@
*1Z
Amt
X@
*1
]
Mute output
X@
(audio off).
Audio or RS-232 unmute
X@
*0Z
Amt
X@
*0
]
Unmute output
X@
(audio on).
Read audio or RS-232 mute
X@
Z
X#]
1 = mute on, 0 = mute off.
Global audio or RS-232 mute
1*Z
Amt1
]
Mute all audio outputs.
Global audio or RS-232 unmute
0*Z
Amt0
]
Unmute all audio outputs.
View output mutes
E
VM
}
X1$
1
X1$
2
...
X1$
n
]
Each
X1$
response is the mute status of an
output, starting from output 1.
n = the maximum number of outputs for your
configuration.
Example :
(MTPX Plus 6432)
E
VM
}
Outputs 2, 3, 5, 26, 27, and 29 are muted. All
other outputs are unmuted.
Mut02202000000000000000000002202000
]
NOTE: The "Mut" portion of the response appears only when the switcher is in Verbose mode 2 or 3 (see the
page 33.
