Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Create ties
NOTES:
•
Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*24$.
•
The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%).
•
The & tie command for RGB and the % tie command for video can be used interchangeably.
•
The & read tie command for RGB and the % read tie command for video can be used interchangeably.
Tie input
X!
video and audio
to output
X@
X!
*
X@
!
Out
X@
•
In
X!
•
All
]
Tie the video and audio from input
X!
to
output
X@
.
Example:
1*3!
Out03•In01•All
]
Tie input 1 to output 3.
Tie input
X!
to output
X@
,
RGBHV only
X!
*
X@
&
Out
X@
•
In
X!
•
RGB
]
Tie input
X!
RGB to output
X@
.
Audio is broken away.
Example (see Notes, above):
10*4&
Out04•In10•RGB
]
Tie input 10 RGB to output 4.
Tie input
X!
to output
X@
,
video only
X!
*
X@
%
Out
X@
•
In
X!
•
Vid
]
Tie input
X!
video to output
X@
.
Audio is broken away.
Example (see Notes, above):
7*5%
Out05•In07•Vid
]
Tie input 7 video to output 5.
Tie input
X!
to output
X@
,
audio only
X!
*
X@
$
Out
X@
•
In
X!
•
Aud
]
Tie input
X!
audio to output
X@
.
Audio is broken away.
Example (see Notes, above):
24*04$
Out04•In24•Aud
]
Tie input 24 audio to output 4.
Read output tie
X@
&
X!]
RGBHV input
X!
is tied to output
X@
.
Read output tie
X@
%
X!]
Video input
X!
is tied to output
X@
.
Read output tie
X@
!
X!]
Video and audio input
X!
is tied to output
X@
.
Read output tie
X@
$
X!]
Audio input
X!
is tied to output
X@
.
NOTE:
X!
= Input number
00 – maximum number of inputs for your configuration (00 = untied)
X@
= Output number
01 – maximum number of outputs for your configuration
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Audio/RS-232 TP input (wire pair 3 and 6 configuration
NOTE: The RS-232 output insert ports, when enabled (
EX$
*0Lrpt
}
) override the audio/RS-232 TP input configuration.
Configure input as audio
X!
*0\
Typ
X!
*0
]
Define the audio/RS-232 input as audio, such
as provided by an MTP 15HD A transmitter.
Configure input as RS-232
X!
*1\
Typ
X!
*1
]
Define the audio/RS-232 input as bidirectional
serial communications, such as provided by an
MTP 15HD RS transmitter.
Read TP input configuration
X!
\
X#]
Show the audio/RS-232 wire pair input
configuration.
RS-232 output inserts and UART ports enables
Enable an RS-232 output
insert
EX$
*1Lrpt
}
Lrpt
X$
*1
]
Enable the RS-232 insert on the
X$
output.
This disables the UART port.
Enable a UART port
EX@
*2Lrpt
}
Lrpt
X@
*2
]
Enable the UART port on the
X@
output. This
disables the RS-232 output insert.
Enable the input on the
output (disable both the
RS-232 output insert and any
UART port)
EX@
*0Lrpt
}
Lrpt
X@
*0
]
Default condition. Disable both the RS-232
insert and UART port on the
X@
output. The
switcher passes the wire pair 3 and 6 of the
tied input.
Enable or disable all ports
EX%
*Lrpt
}
Lrpt00*
X%]
Enable or disable all RS-232 ports or UARTs.
Read the RS-232 output insert
and UART port status
EX@
Lrpt
}
X%]
Show the status of the RS-232 output insert
port and the UART port.
NOTE:
X!
= Input number
00 (all) or 01 – maximum number of inputs for your configuration
X@
= Output number
01 – maximum number of outputs for your configuration
X#
= Audio/RS-232 wire pair input type
0 = audio
1 = RS-232
X$
= RS-232 output insert port
00 (all) or 01 – 16
X%
= RS-232 output insert, UART, or input status
0 = disable
1 = RS-232 output insert
2 = UART port
