Page 27
MTP Series • Reference Information
21
Cables and Connectors
NOTE: Enhanced Skew-Free™ A/V UTP cables are not recommended
for Ethernet/LAN applications.
Enhanced Skew-Free™ A/V Cable
Part Numbers
Enhanced Skew-Free A/V UTP (various lengths)
26-569-xx
Enhanced Skew-Free A/V UTP, bulk
22-141-03
Plenum Enhanced Skew-Free A/V UTP, bulk
22-142-03
RJ-45 Connector
Part Numbers
CAT 6 jack (black)
100-476-01
CAT 6 jack (red)
100-477-01
CAT 6 jack (blue)
100-478-01
CAT 6 jack (orange)
100-479-01
CAT 6 jack (gray)
100-480-01
CAT 6 jack (white)
100-481-01
CAT 6 jack (ivory)
100-482-01
S-video to BNC Adapter
Part Numbers
S-video 4-pin male to 2 BNC female - 8” (20 cm)
26-353-01
S-video 4-pin male to 2 BNC female - 1’ (30 cm)
26-353-02
S-video 4-pin male to 2 BNC female - 3’ (90 cm)
26-353-03
S-video 4-pin male to 2 BNC female - 6’ (1.8m)
26-353-04
S-video 4-pin female to 2 BNC male - 1’ (30 cm)
26-541-02
Skew Compensation Solutions
Skew Equalizer
Part Numbers
SEQ 100 15HD
60-676-01
