MTP Series • Reference Information 17
Reference
Information
This section provides information on:
• Specifications
• Part Numbers
Specifications
Video
Gain .............................................. Unity
Differential phase error .................. <1.0º at 3.58 MHz and 4.43 MHz
Differential gain error .................... <1.0% at 3.58 MHz and 4.43 MHz
Video input
Number/signal type
MTP T AV Series ................. 1 composite video
MTP T SV Series ................. 1 S-video
MTP R AV/SV Series ............ 1 set of proprietary analog signals
Connectors
MTP T AV Series ................. 1 female BNC
MTP T AV AAP ................... 1 female RCA
MTP T SV Series ................. 1 female 4-pin mini DIN
MTP R AV/SV Series ............ 1 female RJ-45
Nominal level ................................. 1 Vp-p for Y of S-video and for composite video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.5 Vp-p with no offset
Impedance .................................... 75 ohms
Return loss .................................... <-30 dB, DC @ 10 MHz
DC offset (max. allowable) ............. 100 mV
Video output
Number/signal type
MTP T AV/SV Series and MTP T AAP Series
1 set of proprietary analog signals
MTP R AV Series ................. 1 composite video
MTP R SV Series ................. 1 S-video
Connectors
MTP T AV/SV Series ............ 1 female RJ-45
MTP T AAP Series ............... 1 female RJ-45 on a 3” (7.6 cm) pigtail
MTP R AV Series ................. 1 female BNC
MTP R SV Series ................. (1) 4-pin mini DIN
Nominal level ................................. 1 V p-p for Y of S-video and for composite video
0.3 V p-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.5 Vp-p
Impedance ..................................... 75 ohms
Return loss .................................... <-35 dB @ 5 MHz
DC offset ...................................... ±20 mV with input at 0 offset
