MTP Series • Reference Information 19
General
Recommended cable type .............. CAT5/5e/6 (shielded or unshielded)
External power supply .................... 100 VAC to 240 VAC, 50-Hz, external; to 12 VDC, 1.0 A, regulated
Power input requirements .............. 12 VDC, 0.2 A
NOTES: • If the distance between the transmitter and receiver is less than 500 feet (150 m) and if
the internal jumper is in setting 2, you can connect a power supply to only one device in a
transmitter/receiver pair.
• If the distance between transmitter and receiver is greater than 500 feet (150 m) or if the
internal jumper is in setting 1 (default), connect a power supply to each device.
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Mounting
Rack mount
MTP T AAP Series ............... Yes, with optional rack panel
All other models................. Yes, with optional 1U deep rack shelf
Furniture or wall mount
MTP T AAP Series ............... Yes, with optional AAP mounting plates
All other models................. Yes, with optional brackets
Enclosure type ............................... Metal
Enclosure dimensions .................... (Depths exclude connectors and cables.)
MTP T AAP Series
Faceplate ........................... 1.4” H x 3.5” W x 0.1” D
(3.6 cm H x 8.9 cm W x 0.3 cm D)
(double space AAP plate)
Transmitter ........................ 1.35” H x 2.7” W x 1.3” D
(3.4 cm H x 6.9 cm W x 3.3 cm D)
All other models ...................... 1.7” H x 2.2” W x 3.0” D
(1U high, one-eighth rack wide)
4.2 cm H x 5.6 cm W x 7.6 cm D
Product weight ............................... 1.0 lbs (0.5 kg)
Shipping weight ............................ 3 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton
(International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
Compliances ............................ CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
NOTES: • All nominal levels are at ±10%.
• Specifications are subject to change without notice.
