Integration Scaling Matrix Switcher • Reference Information

Audio

Routing .......................................... 8 x 2 stereo matrix
Gain ................................................ Unbalanced output: 0dB; balanced output: +6dB
Frequency response .................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise ................................. 0.03% @ 1 kHz at nominal level
S/N ............................................... >90dB at rated maximum output
Crosstalk ....................................... <-80dB @ 1 kHz, fully loaded
Stereo channel separation .......... >90dB @ 1 kHz
CMRR ............................................ >75dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ................... 8 stereo, balanced/unbalanced
Connectors ................................... (8) 3.5 mm captive screw connectors, 5 pole
Impedance .................................... >10 kohms unbalanced/balanced, DC coupled
Nominal level ............................... Configurable: -60dBV (1mV), +4dBu (1.23V), 0dBu (0.775V), -10dBV

(316mV), -20dBV (100mV)

Maximum level ............................ +19.5dBu, (balanced or unbalanced) at 1%THD+N
Input gain adjustment ................. –24dB to +9dB, adjustable per input

Audio output

Number/signal type ................... 2 stereo, balanced/unbalanced
Connectors ................................... (2) 3.5 mm captive screw connectors, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ..................................... ±0.1dB channel to channel
Maximum level (Hi-Z) ................ >+21dBu, balanced or unbalanced at stated %THD+N
Maximum level (600 ohm) ......... >+15dBm, balanced or unbalanced at stated %THD+N

0dBu = 0.775 volts (RMS).

Control/Remote

Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations 2 = TX, 3 = RX, 5 = GND
Ethernet control port .................. 1 RJ-45 female connector
Ethernet data rate ........................ 10/100Base-T, half/full duplex with autodetect
Ethernet protocol ......................... ARP, ICMP (ping), TCP/IP, Telnet
Program control .......................... Extron’s control program for Windows®

Extron’s Simple Instruction Set™ – SIS™
Microsoft Explorer, Netscape Navigator, Telnet

General

Power ............................................ 100VAC to 240VAC, 50/60 Hz, 60 watts, internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing

Rack mount .................................. Yes
Enclosure type .............................. Metal
Enclosure dimensions ................. 5.25" H x 17.5" W x 11.2" D (3U high, full rack width)

13.3 cm H x 48.3 cm W x 28.4 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)

Product weight ............................. 11.2 lbs (5.1 kg)
Shipping weight ........................... 17 lbs (7.7 kg)
