4-9

Integration Scaling Matrix Switcher • Programmer’s Guide

Command/response table for SIS commands (cont’d)

Command

ASCII Command

Response

Additional description

(host to switcher)

(switcher to host)

Brightness

The

X2

value specified is the output to which the adjusted input is tied.

Set

a specific brightness value

X2

*

X11

Y

X2

Brt

X11

Specify the brightness
adjustment.

Increment

brightness value

X2

+Y

X2

Brt

X11

Increase the brightness.

Decrement

brightness value

X2

–Y

X2

Brt

X11

Decrease the brightness.

View

the brightness value

X2

Y

X11

Show the brightness setting.

Contrast

The

X2

value specified is the output to which the adjusted input is tied.

Set

a specific contrast value

X2

*

X11

^

X2

Con

X11

Specify the contrast adjustment.

Increment

contrast value

X2

+^

X2

Con

X11

Increase the contrast.

Decrement

contrast value

X2

–^

X2

Con

X11

Decrease the contrast.

View

the contrast value

X2

^

X11

Show the contrast setting.

Horizontal size

Set

a specific horizontal size

X2

*

X12

:

X2

Hsz

X12

Specify the horizontal size.

Increase the horizontal size

X2

+

:

X2

Hsz

X12

Widen the picture.

Decrease the horizontal size

X2

:

X2

Hsz

X12

Make the picture narrower.

View

the horizontal size

X2

:

X12

Show the horizontal size.

Vertical size

Set

a specific vertical size

X2

*

X12

;

X2

Vsz

X12

Specify the vertical size.

Increase

the vertical size

X2

+

;

X2

Vsz

X12

Make the picture taller.

Decrease

the vertical size

X2

;

X2

Vsz

X12

Make the picture shorter.

View

the vertical size

X2

;

X12

Show the vertical size.

Horizontal shift

Set

a specific horizontal position

X2

*

X13

H

X2

Hph

X13

Specify the horizontal position.

Increment

right

X2

+H

X2

Hph

X13

Shift the picture right.

Decrement

left

X2

–H

X2

Hph

X13

Shift the picture left.

View

the horizontal position

X2

H

X13

Show the horizontal position.

Vertical shift

Set

a specific vertical position

X2

*

X13

/

X2

Vph

X13

Specify the vertical position.

Increment

up

X2

+/

X2

Vph

X13

Shift the picture up.

Increment

down

X2

–/

X2

Vph

X13

Shift the picture down.

View

the vertical position

X2

/

X13

Show the vertical position.

Top blanking

Set

a top blanking value

X2

*

X14

(

X2

Blt

X14

Example:

1*2(

1Blt2

Blank the top two lines of the
program outut.

Increment

top blanking value

X2

+(

X2

Blt

X14

Increase blanking value 1 line.

Decrement

top blanking value

X2

–(

X2

Blt

X14

Decrease blanking value 1 line.

View

the top blanking value

X2

(

X14
