15

2001 - INLINE, Inc. IN31608 OPERATION MANUAL - REV 1.6 1/4/01
COMMAND DESCRIPTION RESPONSE
PCHxx
‘hex code’ Load ‘hex code’ in Projector Control Code block xx. 60 characters maximum
Example 1: [PCH400102030405] loads buffer 40 with the five characters:
HEX: 01, 02, 03, 04, 05 or Binary: 0000 0001, 0000 0010,
0000 0011, 0000 0100, 0000 0101
Example 2: [PCH6F414243] loads buffer 6F with the 3 characters: HEX:
41, 42, 43 or Binary: 0100 0001, 00100 0010, 0100 0011.
Note that [PCL50ABC] achieves the same results as Example 2. [OK]
PCLxx
‘ascii code’ Loads ‘ascii code’ code in Projector Control Code block xx. 60 characters
maximum.
Example 1: [PCL6FaAbBcC] This is the code for recall memory 16 in
Matrix Mode. It loads the ASCII sequence “aAbBcC.”
Example 2: [PCL58aAbBcC] This is the code for Function 1 On in both
Matrix and Direct Modes. It loads the ASCII sequence “aAbBcC.” [OK]
PCP0 Disable projector control port [OK]
PCP1 Enable projector control port [OK]
PCP2 Transmit projector control code through serial and projector ports (for test).
Once enabled this feature is disabled by cycling power. [OK]
PCPDx Set code delay where x is as follows:
x = 0 0 msecs
x = 1 1 msecs
x = 2 5 msecs
x = 3 10 msecs
x = 4 20 msecs
x = 5 50 msecs
x = 6 100 msecs
Example: [PCPD5]
Set projector code delay to 50 msec.
[OK]
Set projector port per the following table.
Example: [PCPPA3]
Set the projector port for 9600 baud, even parity, and RS-485.
BAUD PARITY RS-232 RS-485
1200 None 00 80
1200 Odd 10 90
1200 Even 20
A0
2400 None 01 81
2400 Odd 11 91
2400 Even 21
A1
4800 None 02 82
4800 Odd 12 92
4800 Even 22
A2
9600 None 03 83
9600 Odd 13 93
9600 Even 23
A3
19200 None 04 84
19200 Odd 14 94
19200 Even 24 A4
38400 None 05 85
38400 Odd 15 95
38400 Even 25 A5
57600 None 06 86
57600 Odd 16 96
PCPPxx
57600 Even 26 A6
[OK]
