12
IN31608 OPERATION MANUAL - REV 1.6 1/4/01
2001 - INLINE, Inc.
COMMAND
DESCRIPTION
RESPONSE
ACI6
Set to 9600 baud rate, default setting [OK]
ACI7
Set to 19200 baud rate
[OK]
CALLxx
(Matrix Mode)
Recall configuration from SETUPxx
xx: 2 byte ASCII code, 01 <= xx <= 16.
Example: [CALL16] Recall configuration previously saved to
Memory 16.
Note: See [SAVExx]
[OK]
CMDCD0
Set the command code to [ ], default setting [OK]
CMDCD1
Set the command code to { }
[OK]
CMDCD2
Set the command code to ( )
[OK]
CMDCD3
Set the command code to < >
[OK]
CNFxxyyzz
(Matrix Mode)
Configure the board groups for individual control over the RGB, Sync and
Audio boards (RS-232 control only)
xx: Represents boards in Group 1
yy: Represents boards in Group 2
zz: Represents boards in Group 3
where xx, yy, and zz are as follows:
01 Video boards only
08 Sync boards only
20 Audio boards only
09 Video and Sync boards
21 Video and Audio boards
28 Sync and Audio boards
29 All boards (Video, Sync and Audio boards)
00 No Boards
No boards
Note: Boards can only be configured to one group.
Example 1: [CNF 09 20 00] (spaces added for clarity)
Assign Video and Sync boards to Group 1 and the Audio boards to
Group 2.
Example 2: [CNF 29 00 00] (spaces added for clarity)
Assign all boards to Group 1.
Note: Use with [L] command.
[OK]
FP
Toggle between front panel enable and disable
[OK]
FP0
Disable the front panel operation
[OK]
FP1
Enable the front panel operation, default setting [OK]
INii
(Direct Mode)
For the Direct Mode select input ii, 00 <= ii <= 16
ii: Input #, a 2 byte ASCII code. If ii = 00, no input is selected,
resulting in a blank output.
[OK]
INFO
Get firmware version
[Version 2.3 10/21/99]
IOoi
1
i
2
i
3 . . .
i
16
(Direct Mode)
For the Direct Mode, assign inputs to output o
1 <= o <= 8 , i
n
= O or C
o: Output # to assign inputs to
i
n
: ‘O’ for open or ‘C’ for closed
Example 1: [IO1CCCCOOOOOOOOOOOO]
Assign Inputs 1, 2, 3 and 4 to Output 1.
Example 2: [IO8OCOCOCOCOCOCOCOC]
Assign even Inputs to Output 8.
[OK]
