Command/response table for SIS commands (continued)
NOTE:
X2)
= Link or input status
0 = light or signal input not detected
1 = light or signal detected
X2!
= Transmission mode
SM = singlemode
MM = multimode
X2@
= Transmitter or receiver
Tx = transmitter
Rx = receiver
X2#
= Firmware version
v.vv
X2$
= Internal temperature
nnnF•nnC
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Information requests
Information request
I
1Lnk
X2)
•2Lnk
X2)
•RGB
X2)
•Aud
X2)
•
X2!
•
X2@]
The unit responds with the current status (signal
detected) of optical link 1, optical link 2, the
video input, and the audio link; the fiber optic
transmission mode (singlemode or multimode); and
the device type (Tx or Rx).
NOTE: The receiver monitors the primary (transmitter-TX to receiver-Rx) fiber cable. If the PC is connected to the transmitter and the
receiver-Tx-to-transmitter-Rx fiber cable is not connected, for the
I
and
1S
commands, the transmitter reports
1link0 regardless
of the status of the primary cable.
Show firmware version
Q
X2#]
Example:
Q
1.23
]
The factory-installed firmware version is 1.23
(sample value only).
Request part number
N
60-nnn-nn
]
See “
Request part number of
other unit
1N
60-nnn-nn
]
See “
Show link 1 status
1S
X2)]
Light status on transmitter-Tx-to-receiver-Rx cable.
Show link 2 status
2S
X2)]
Light status on receiver-Tx-to-transmitter-Rx cable.
Show input video status
3S
X2)]
Show transmitter video input status.
Show input audio status
4S
X2)]
Show transmitter audio input status.
Show temperature
20S
X2$]
Show temperature in degrees Fahrenheit and Celsius.
Resets
Reset audio
EZA
}
Zpa
]
Reset audio setting to default levels (0 dB gain).
Reset memory presets
EZG
}
Zpg
]
Reset (erase) all memory presets.
System reset
EZXXX
}
Zpx
]
Reset all settings to factory defaults.
