Extron Electronics DVI DA Plus Series User Guide User Manual
Page 5

Contents
Introduction ............................................
1
About this Guide ........................................... 1
About the DVI DA Plus Series ....................... 1
Features ......................................................... 2
Installation ..............................................
3
Installation Overview .................................... 3
Rear Panel Features....................................... 4
DVI Connector Pin Assignments ............... 6
Operation ................................................
7
Front Panel Features ..................................... 7
Operation ...................................................... 7
EDID Minder .................................................. 8
Disabling the EDID Minder ........................... 8
EDID Lock ..................................................... 10
Pre-emphasis................................................ 11
Troubleshooting .......................................... 12
Specifications .........................................
13
Reference Information ..........................
14
Included Parts .......................................... 14
Optional Accessories ............................... 14
Mounting ................................................
15
Tabletop placement .................................... 15
Rack mounting ............................................ 15
UL Guidelines for Rack Mounting .......... 15
Rack Mounting the DVI DA4 Plus ........... 16
Rack Mounting the DVI DA6 Plus
and DVI DA8 Plus ................................... 16
Under-desk Mounting ................................. 16
DVI DA Plus Series • Contents
v
