Installation Checklist
† Ensure that the input sources, the distribution amplifier and the output
displays are all turned off and all power sources and signal cables are
disconnected.
† Mount the unit as described in “ Mounting ”, (see page 15).
† Connect the cables (see “ Rear Panel Features ”, on page 4).
† If required, configure the internal DIP switches to disable EDID (see
page 8) from certain outputs, to activate the EDID Lock mode (see
page 10), or to enable pre-emphasis (see page 11).
† Plug in the power supply (see page 4).
† Turn on the display devices.
† Turn on the input devices (see “ Operation ”, on page 7).
