Specifications

Video

Maximum data rate ........................ 4.95 Gbps (1.65 Gbps per color)
Maximum pixel clock ...................... 165 MHz
Resolution range ............................ Up to 1920x1200 or 1080p @ 60 Hz
Formats .......................................... RGB and YCbCr digital video
Standards ....................................... DVI 1.0, HDMI 1.2

Video input

Number/signal type ........................ 1 single link DVI-D (or HDMI*)
Connectors .................................... 1 female DVI-I

Video output

Number/signal type ........................ 4, 6, or 8 (depending on model) single link DVI-D (or HDMI*)
Connectors .................................... 4, 6, or 8 female DVI-I

NOTE:

*Appropriate DVI-D to HDMI cables or adapters are required for HDMI signal input/output.

General

External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, regulated
DVI DA4 Plus .................................. 1 A
DVI DA6 Plus, DVI DA8 Plus ............ 3 A
Power input requirements .............. 12 VDC

DVI DA4 Plus ........................... 1.0 A (max.)
DVI DA6 Plus, DVI DA8 Plus ..... 1.5 A (max.)

Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling .......................................... Convection, no vents
Mounting

Rack mount ............................. Yes, with optional rack (DVI DA4 Plus) or included brackets (DVI DA6 or 8 Plus)
Furniture mount ...................... Yes, with optional under-desk mounting kit

Enclosure type ................................ Metal
Enclosure dimensions

DVI DA4 Plus ........................... 1.75" H x 8.75" W x 3.0" D (1U high, half rack wide)

(4.4 cm H x 22.2 cm W x 7.6 cm D)
(Depth excludes connectors.)

DVI DA6 Plus, DVI DA8 Plus ..... 1.75" H x 17.5" W x 8.5" D (1U high, full rack wide)

(4.4 cm H x 44.4 cm W x 21.6 cm D)
(Depth excludes connectors.)

Product weight ............................... 2.8 lbs (1.3 kg)
Shipping weight ............................. 5 lbs (3 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance

Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI

MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor

NOTE:

All nominal levels are at ±10%

Specifications are subject to change without notice.
