Specifications, Parts, and Accessories
A-3
RF audio input
Number/signal type ................... 1 (as part of the RF signal)
0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu
Audio output
Number/signal type ................... 1 balanced/unbalanced;
stereo for NTSC, PAL B/G, PAL D/K;
mono only for PAL I
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ± 0.5 dB channel to channel
Nominal level ............................... 0 dBu
Output level .................................. 1 Vrms (max.)
Control/remote — AVT 100
Serial control port ........................ RS-232; 3.5 mm captive screw connector,
5 pole
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial/IR control pin configurations
1 = TX, 2 = RX, 3 = GND, 4 = modulated
IR, 5 = +12 VDC
IR controller module ................... AVT Remote (optional)
30' maximum, 40 degrees off axis
Program control ........................... Extron’s control/configuration program
for Windows ®
Extron’s Simple Instruction Set (SIS ™ )
General
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external,
autoswitchable; to 12 VDC, 1 A (max.),
regulated
Power input requirements ......... 12 VDC, 0.5 A
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Cooling .......................................... Convection, unvented
Rack mount ................................... Yes, with optional 1U, 9.5" deep rack shelf,
(RSU 129, part #60-190-01 or RSB 129,
#60-604-01)
Enclosure type .............................. Metal
Specifications
RF video input
Number/signal type ................... 1 radio frequency (RF)
Connectors
NTSC model ..................... 1 female F connector
PAL model ........................ 1 female IEC 169-2, 75 ohm connector
Sensitivity ..................................... -20 to +20 dBmV
Frequency range .......................... 55 MHz to 855 MHz
NTSC over the air TV channels . 2-69
Japan .................................. 1-62
NTSC CATV cable channels ...... 2-125
Japan .................................. 1-63
PAL over the air TV and cable channels
48 MHz to 855 MHz
Impedance .................................... 75 ohms
Vertical frequency
NTSC model ..................... 60 Hz
PAL model ........................ 50 Hz
Video output
Number/signal type ................... 1 composite video
Connectors .................................... 1 BNC female
Nominal level ............................... 1 Vp-p for composite video
Minimum/maximum levels ...... 0.4 V to 1.0 Vp-p (follows input)
Impedance .................................... 75 ohms
DC offset ....................................... ±10 mV with input at 0 offset
Sync
Standards
NTSC model ..................... NTSC 3.58
International model ......... PAL
Audio
THD + Noise ................................ NTSC: 0.4% @ 1 kHz
PAL: 0.6% @ 1 kHz
S/N ................................................ NTSC: -55 dB @ 1 kHz
PAL: -58 dB @ 1 kHz
Stereo channel separation .......... >35 dB @ 1 kHz
