Extron Electronics AVT 100 - Manual (Page 17)

AVT 100 • Operation
Operation, cont’d
AVT 100
4
Chapter Four
Software Configuration and
Control
Using Simple Instruction Set (SIS ™ ) Commands
Windows ® -Based Control Software
3-10
Saving a preset using the IR remote
To assign a channel number to one of the 198 available presets,
1 . Switch to the channel that you want to assign. (See
“Selecting a channel (tuning) using the IR remote,” on the
previous page.)
2 . Enter the preset number to which you want to assign the
current channel.
3 . Press Save. The AVT 100 saves the preset, and displays
“P” and the preset number as confirmation. After
3 seconds, the display returns to the channel number that
you just saved.
N If an invalid preset number is entered, no preset is saved.
