Software Configuration and Control, cont’d
AVT 100 • Software Configuration and Control AVT 100 • Software Configuration and Control 4-5
Command/r
esponse table for SIS commands
Command
ASCII
Response
Additional
(host to A
VT)
(A
VT to host)
information
Memory pr
eset
Save pr
eset (active channel)
X3
,
Spr
X3
X3
= P
resets
01-99.
Recall pr
eset
X3
.
Rpr
X3
chn
X1
Save pr
eset (user
-specified channel)
X1
*
X3
,
pr
e
X3
chn
X1
X1
channel values:
NTSC antenna: 002-069 NTSC CA
TV
: 002-125
P
A
L
antenna (TV) and CA
TV
:
048-855
V
iew all pr
esets
Esc
.
p
re01chnxxx
thr
ough pr
e99chnxxx
V
ideo mute
Mute on
1B/b
Vmt
X2
Mutes video output. For
X2
: 0 = of
f; 1 = on.
Mute of
f
0B/b
Vmt
X2
Unmutes video output.
V
iew video mute status
B
/
b
Vmt
X2
Shows muting status.
Audio mute Mute on
1Z/z
Amt
X2
Mutes audio output.
Mute of
f
0Z/z
Amt
X2
Unmutes audio output.
V
iew the audio mute status
Z
/
z
Amt
X2
Shows muting status.
4-4
Symbol definitions
= CR/LF (carriage return/line feed) (hex 0D 0A)
= Soft carriage return (no line feed)
• = Space
Esc = Escape key
X1 = Channel number
NTSC antenna: 002 – 069
NTSC cable: 002 – 125
NTSC Japan antenna: 001-062
NTSC Japan cable: 001-063
PAL antenna and cable: 48 – 855
X2 = Muting/Executive mode
0 = Off
1 = On
X3 = Presets 1 – 99 (The preset number cannot be more than two digits.)
X4 = Antenna or cable DIP switch setting
0 = Antenna (TV)
1 = CATV (cable)
X5 = PAL standard selection
0 = B/G (default)
1 = D/K
2 = I
X6 = Part number
X7 = Audio adjustment level: -63 through +12
X8 = Gain level: 0 – 12
X9 = Attenuation level: 0 – 63
If a command is not case-sensitive, this is indicated by showing the
command letter in uppercase, followed by a slash (/), then the same
letter in lowercase.
Examples: B/b, Z/z
