Software Configuration and Control, cont’d
AVT 100 • Software Configuration and Control AVT 100 • Software Configuration and Control 4-7
Command/r
esponse table for SIS commands (continued)
Command
ASCII
Response
Additional information
(host to A
VT 100)
(A
VT 100 to host)
Executive mode Disable
0X/x
Exe0
Enables contr
ol via the front panel
by disabling executive mode.
Enable
1X/x
Exe1
Locks out contr
ol fr
om the
fr
ont panel.
V
iew Status
X
/
x
Exe
X2
Shows whether executive mode is on or of
f.
Query firmwar
e version
Query firmwar
e version
Q
/
q
x.xx
Shows curr
ent firmwar
e
version.
x.xx
is the format of the
version number
.
Request Part Number Request
A
VT 100 part number
N
/
n
X6
X6
values:
NTSC = 60-647-01. P
A
L
= 60-647-02.
Reset to default settings (Zap command) Zap settings/memories
Esc
zXXX
ZapXXX
The default settings ar
e:
T
une mode
All presets removed Auto-Scan channels cleared
4-6
Command/r
esponse table for SIS commands (continued)
Command
ASCII
Response
Additional
(host to A
VT)
(A
VT to host)
information
P
AL standar
d selection (P
AL version only)
Select standar
d
X5
S/s
Sys
X5
Select P
A
L
standar
d
.
X5
values ar
e:
0 = B/G (default). 1 = D/K. 2 = I.
V
iew status
S/s
Sys
X5
Show the curr
ent P
A
L
standar
d
.
Request information Request channel number
I/
i
TVC
X1
X1
= channel number
.
Audio gain and attenuation (NTSC model only) Set specific gain
X8
G
Aud
X7
Set the gain to
X7
dB.
Range for gain (
X8
) is 0 to +12.
Set specific attenuation
X9
g
Aud
X7
Set the attenuation to
X7
dB.
Range for attenuation (
X9
) is 0 to +63.
Incr
ement gain or
attenuation
+G/g
Aud
X7
Set audio level to
X7
dB by increasing
gain or attenuation. Default audio level is 0dB.
Decr
ement gain or attenuation
–
G/g
Aud
X7
Set audio level to
X7
dB by decr
easing
gain or attenuation.
V
iew gain or attenuation
G/g
X7
V
iew curr
ent audio level in dB.
