Software Configuration and Control, cont’d

AVT 100 • Software Configuration and Control

AVT 100 • Software Configuration and Control

4-11

Command/r

esponse table for special function SIS commands (continued)

Command

ASCII c

ommand

Response

X!

values

(host to A

VT)

(A

VT to host)

and additional descriptions

Audio configuration

Audio output mode

X!

* 7 #

Mon

X!

0 = Ster

eo.

1 = Mono.

2 = Select left channel and output as mono.*

3 = Select right channel and output as mono.*

4 = Output same as input (R to R, L to L)*

5 = Output opposite of input (R in to L out,

L in to R out)*.

* This configuration is available only in P

A

L

versions, when Dual Channel is detected.

Audio configuration setup depends on the incoming audio signal. If ster

eo audio is detected on the curr

ent

channel, mode 0 (ster

eo) is the default. If a dual language channel (e.g., English on the left channel and Spanish

on the right) is detected on a selected TV/Cable channel, mode 2 (select left channel and output as mono) is the

default. The user can overwrite the default setting by setting up audio configuration via SIS command or the

W

indow’

s-based contr

ol softwar

e, and the user

’s setting is saved.

Example:

1 * 7 #

M

on 1

Mono output.

V

iew audio mode

7

#

Mon

X!

IR r

emote contr

ol access on/of

f

IR r

eceiver on/of

f

X!

* 9#

Rmt

X!

0 = IR enabled (default).

1 = IR disabled.

Example:

1*9#

Rmt

l

T

urn IR contr

ol of

f.

V

iew IR r

eceiver status

9

#

Rmt

X!

4-10

Command/r

esponse table for special function SIS commands (continued)

Command

ASCII command

Response

X!

values

(host to A

VT)

(A

VT to host)

and additional descriptions

Pr

esets

Delete pr

eset

X!

* 5 #

Del

X!

1-99 pr

esets each for cable and TV

Example

:

25 * 5 #

Del 025

Delete pr

eset 25.

Change channel

Incr

ement

channel

+ 6 #

TVC

X1

X1

values for NTSC:

002-069 (TV channel)

002-125 (cable channel)

X!

values for NTSC in Japan:

001-062 (antenna TV channel)

001-063 (CA

TV channel)

X1

values for P

AL:

048-855 (antenna and CA

TV channel)

Decr

ement

channel

- 6 #

TVC

X1

See

X1

values for decrementing the channel.

Set TV Channel

X1

* 6 #

TVC

X1

See

X1

values for setting the channel.

Example:

056 * 6 #

T

VC 056

Set TV channel to 56.

V

iew channel

6 #

TVC

X1

V

iew DIP switch setting

Antenna/cable selection

8

#

D

ip

X4

Shows whether the

A

VT is set to antenna

(TV) or CA

TV (cable) mode.

For

X4

:

0 =

Antenna.

1 = Cable.

Example

:

8 #

Dip1

DIP switch has been set to cable.
