Local control panel – Bell & Gossett P2001489 Integrated Technologic with Sensorless Control User Manual
Page 24
Local control panel
The controller comes equipped with a local control panel (LCP). The panel allows the user
to view the status of the controller, pump, and system without entering the parameter list.
Consult the Technologic Pump Controller IOM for details on programming the controller.
The default configuration is shown in the following figure.
6
5
4
8
7
9
2
3
1
Figure 14: Default configuration
1. Controller Status
2. Motor HP (Parameter 0–24)
3. Feedback / actual pressure (Parameter 0–20)
