Setup 1 Setup 2
Constant Pressure
Wired Pressure Transducer
Constant Flow
Wired Flow Transducer
Parameter Number Parameter Name Default Value for Set-up 1 Default Value for Set-up 2 Parameter Description
22-86 Speed at Design Point [Hz] 60.0 Hz 60.0 Hz Speed required to maintain
the design point. Use this
parameter when flow
compensation is enabled.
See figure 3, point B.
22-87 Pressure at No Flow Speed 0.000 0.000 Pressure developed at no
flow speed. Use this
parameter when flow
compensation is enabled.
See figure 2, point A.
5-10 Terminal 18 Digital Input Start Start DI 18 function
5-11 Terminal 19 Digital Input No Function No Function DI 19 function
5-12 Terminal 27 Digital Input No Function No Function DI 27 function
6-50 Terminal 42 Output Speed 4-20mA Speed 4-20mA Analog output function
5-40 Function Relay Relay 1: No Alarm Relay 2:
Running
Relay 1: No Alarm Relay 2:
Running
Relay 1 and 2 function. See
note below on how to
program this parameter.
Table 14: My personal menu parameters for set-ups 3 and 4
Setup 3 Setup 4
Sensorless Pressure
Control
Sensorless Flow Control
Parameter Number Parameter Name Default Value for Set-up 3 Default Value for Set-up 4 Parameter Description
20-21 Setpoint 1 15.0 150.0 Process setpoint. The
controller will adjust speed
to maintain this value.
20-00 Feedback 1 Source Sensorless Pressure Sensorless Flow Feedback source for the
PID controller, transducer
input source.
20-12 Reference/Feedback Unit psi GPM Transducer feedback units
20-13 Min Reference/Feedb. 0.0 0.0 Minimum feedback value
for the transducer.
20-14 Max Reference/Feedb. 40.0 300.0 Maximum feedback value
for the transducer.
3-41 Ramp 1 Ramp Up Time 10 s 10 s Ramp up time (0 to full
speed). Increasing this
time will produce a slower
ramp up.
3-42 Ramp 1 Ramp Down Time 10 s 10 s Ramp down time (full
speed to 0). Increasing this
time will produce a slower
ramp down.
System Setup and Operation
Integrated Technologic ® with Sensorless Control INSTRUCTION MANUAL 35
