My personal menu
My Personal Menu has been configured at the factory to contain 20 parameters that are
commonly used in pumping applications. The parameters that are shown in My Personal
Menu vary depending on which setup is active. Refer to the Setup and Commissioning
section for details on My Personal Menu parameters.
NOTICE:
Quick Setup, Function Setups, and Smart Start submenus contain motor parameters. The
motor parameters have been configured at the factory for the motor that has been
shipped with the system. Improperly configuring motor parameters may cause controller
malfunction.
Main Menu
The parameters in the Main Menu are grouped by category. Note that some groups are
not visible unless the appropriate option card is installed. For a complete list and detailed
description for each parameter refer to document number MG11CD02, available for
download at www.danfoss.com. The parameter groups in the Main Menu are:
Table 9: Main menu parameter groups
Parameter Group Name
0 Operation/Display
1 Load and Motor
2 Brakes
3 Reference/Ramps
4 Limits/Warnings
5 Digital In/Out
6 Analog In/Out
8 Comm. and Options
9 Profibus*
10 CAN Fieldbus*
11 LonWorks*
13 Smart Logic
14 Special Functions
15 Drive Information
16 Data Readouts
18 Info & Readouts
20 Drive Closed Loop
21 Ext. Closed Loop
22 Appl. Functions
23 Time-based Functions
24 Appl. Functions 2
25 Cascade controller
26 Analog I/O Option MCB 109*
* Appropriate option card must be installed
