HandyLab 600 Operation
ba77064e01 03/2014 17
4.4 Navigation
4.4.1 Operating modes
4.4.2 Measured value display
In the measured value display, you can

open the menu for calibration and measurement settings with
(short keystroke)
 open the Storage & config menu with the sensor-independent
settings by pressing (long keystroke, approx. 2 s).
 change the display in the selected measuring screen (e. g. pH <-> mV) by
pressing .
4.4.3 Menus and dialogs
The menus for settings and dialogs in procedures contain further subelements.
The selection is made with the <><> keys. The current selection is dis-
played with a frame.

Submenus
The name of the submenu is displayed at the upper edge of the frame. Sub-
menus are opened by confirming with . Example:
Operating mode Explanation
Measuring The measurement data of the connected sensor are
shown in the measured value display
Calibration The course of a calibration with calibration information,
functions and settings is displayed
Storing in
memory The meter stores measuring data automatically or man-
ually
Transmitting
data The meter transmits measuring data and calibration
records to a USB-B interface automatically or manually.
Setting The system menu or a sensor menu with submenus,
settings and functions is displayed
General
Interface
Clock function
Service information
Reset
System
01.02.2014
08:00
Back
