Help windows, Window text help text – Xylem IM043 AQUAVAR Variable Speed Pump Control User Manual
Page 71
70
Help Windows
Window text
Help Text
Test Run Man.
Start test run with Increase + Decrease
(Inc + Dec)
Test Frequency
Test frequency
30.0 hz
Boost Test Run
Test boost
5%
Submenu
Submenu: errors; to enter push select at least
Error
one second
Conveyor Limit
Value at which pump system shall be
deactivated
Delay
Enter a time the pump is allowed to run after a
2 sec
suction line sensor has activated, or conveyor
limit has been reached.
Error Reset
Automatic error reset
On
Clear Errors
Clear error history
0000
Operating Hours
Total AQUAVAR controller operating time
xxxxh
(reset counters: press inc + dec)
Disp. Contrast
Display contrast
100%
Set Password
Modify password, 0066 Default
0000
Lock function
On > keypad locked: off > changes allowed
off
Heating
Internal heating element on/off
Submenu
Submenu load default parameters to enter
Default Values
push select at least 1 second.
Default USA/Europe
Reset to default parameters
Inc + dec
Save ???
Press Inc + Dec to save entered values
Inc + dec
