AQUAVAR Controller Model ________________ Transducer Model ______________________
AQUAVAR Serial Number _________________ Transducer Rating ______________________
Date purchased _________________
Purchased from _________________
Pump Model _________________ Software Version _______________________
Pump Code Number _________________
Program Record
Please use the following to record the final values programmed into the AQUAVAR controller after installation.
Required Value ___________________ (select) Intensity 1_________________________ (%)
Autostart ________________________ (on/off) Intensity 2_________________________ (%)
Password _______________________ (value) Pressure Increase __________________ (PSI)
Window ___________________________ (%) Pressure decrease __________________ (PSI)
Ramp Hysteresis _____________________ (%) Enable Sequence Control ______________ (Hz)
Ramp 1 _______________________ (seconds) Switch Interval __________________ (hours)
Ramp 2 _______________________ (seconds) Optional Value ________________________
Ramp 3 _______________________ (seconds) Synchron Limit _____________________ (Hz)
Ramp 4 _______________________ (seconds) Synchron Window ___________________ (Hz)
Max. Frequency _____________________ (Hz) Pump Address _________________ (# or off)
Min. Frequency _____________________ (Hz) ADC Reference __________________ (select)
Config. F Min. __________________________ Freq. Lifting _______________________ (Hz)
Stop - Delay F Min. ______________ (seconds) Lift Intensity _______________________ (%)
Boost _____________________________ (%) Analog out _____________________ (select)
Sensor Curve ___________________________ Pressure Unit ____________________ (select)
Sensor Normalize - 20mA _____________ (PSI)
Test Run After _________________ (in hours)
Mode __________________________ (select) Test Frequency _____________________ (Hz)
Regulation Mode _______________________ Test Boost _________________________ (%)
Start Value _________________________ (%)
Conveyor Limit ____________________ (PSI)
Config. Second Value ____________________ Delay Time ___________________ (seconds)
Relay Config. __________________________ Error Reset _____________________ (on/off)
Offset Input ____________________________ Display Contrast ____________________ (%)
Level 1 ____________________________ (%) Lock Function ___________________ (on/off)
Level 2 ____________________________ (%) Heating ________________________ (on/off)
AQUAVAR Controller Owner’s Information Record
