69
Help Windows
Window text Help Text
Submenu Submenu: synchronous regulation; to enter
Synch. control push select at least one second.
Synchron limit Frequency limit to enable the synchronous
35.0 Hz regulation
Synchron window Frequency offset for the frequency limit which
5.0 hz activates the synchronous regulation
Pump sequence Diagnostics: Pump sequence and status
Adr 1 Hold P1
BUSARBIT DIAG Diagnostics: Bus arbitration (this pump)
0
SUBMENU Submenu: Serial Interface; to enter push select
RS485 Interface at least one second.
Pump Address SIO address of the pump
off
ADC Reference Pressure or frequency reference enabled by local
local ADC or by SIO
Frequency Lifting Frequency limit for pressure lift
30.0 hz
Lift Intensity
Max. lift in % of pressure set point at max.
0.0% frequency
Analog out Meter output: frequency; pressure
actual value
Dimension unit Displayed dimension unit
PSI
Test run Time interval for test run 10 - 100 hr. or
after 24 h deactivated (inc+ dec)
Submenu Submenu pump test manual; to enter push
Test Run Man. select at least one second
