Programming – Xylem IM043 AQUAVAR Variable Speed Pump Control User Manual
Page 46
Hold the key to return to the synchronous
control submenu.
Hold the key again to return to the sequence
control submenu.
Press the key to advance to:
Hold the and arrows until:
Using the above settings, when there is system demand, the AQUAVAR pump will start first and
maintain pressure until it reaches 58 Hz. At that point, the relay will start the slave pump at full
speed. As soon as the slave pump is started the AQUAVAR pump will reduce its speed and continue
to vary to maintain constant pressure. If demand is reduced and the AQUAVAR controlled pump
slows to 40 Hz, the slave pump will be turned off. At this point, the AQUAVAR controlled pump
would increase speed to continue to maintain constant pressure.
Programming
45
t
t
SUbMENU
SyNCh. CONTROL
SUbMENU
SEQUENCE CONTROL
SAVE ??? +
t
t
SAVE ??? SAVED
*
*
*
When using the slave pump, this pump will start and go to full speed immediately. You must
use your common values and mechanical devices to prevent “run out” or over pressure of this
system or “hunting” or oscillation of pressure will occur.
Note
