Page 69
68
Help Windows
Window text
Help Text
Regulation Mode
Pumping regulation mode, normal or increased
Start Value
Start value Allows system pressure drop
%, PSI
before unit starts.
Config. 2nd Required Value
Configuration of a second value
Off
Relay Configuration
Relay configuration
Run Motor
Submenu
Submenu offset: to enter push
Offset
select for at least 1 second.
Offset Input
Selection of offset input
Off
Level 1
Start level for offset 1
XX.X %
Level 2
Start level for offset 2
XX.X%
Intensity 1
Intensity of offset 1
XX.X%
Intensity 2
Intensity of offset 2
XX.X%
Submenu
Submenu seq. control; to enter push select
Seq. Control
at-least one second
Pressure Incr.
Pressure increment at switching of additional
4 PSI
pump
Pressure dec.
Pressure decrement for consecutive pumps
4 PSI
Enable seq. ctl.
Frequency limit enable sequence control
40.0 hz
Switch interval
Time interval pump sequence change,
12h
alternate time.
