Xylem IM250R03 Aquavar CPC-FD - Manual (Page 31)

31
500…600 Volt, Terminals
500 … 600 Volt
Frame
Size
Power Wiring Data
Vendor
Part Number
HP Type Code
Circuit
Breaker
Disconnect
Switch
Motor
Terminals
Ground
Lugs
NEMA
1 & 12
2 CPC5002xFD R2
#6
62 in-lbs
#8
7 in-lbs
#6
12 in-lbs
#6
35 in-lbs
ACS550-PD-02A1-
6+N2000+X1555
3 CPC5004xFD R2
ACS550-PD-04A1-
6+N2000+X1555
5 CPC5006xFD R2
ACS550-PD-06A1-
6+N2000+X1555
7.5 CPC5009xFD R2
ACS550-PD-09A1-
6+N2000+X1555
10 CPC5011xFD R2
ACS550-PD-11A1-
6+N2000+X1555
15 CPC5017xFD R2
ACS550-PD-17A1-
6+N2000+X1555
20 CPC5022xFD R3
#3
62 in-lbs
#3
24 in-lbs
#3
50 in-lbs
ACS550-PD-22A1-
6+N2000+X1555
25 CPC5027xFD R3
ACS550-PD-27A1-
6+N2000+X1555
30 CPC5032xFD R4
#1
62 in-lbs
#4
18 in-lbs
#1
48 in-lbs
#2
50 in-lbs
ACS550-PD-32A1-
6+N2000+X1555
40 CPC5041xFD R4
ACS550-PD-41A1-
6+N2000+X1555
50 CPC5052xFD R4
#1
55 in-lbs
ACS550-PD-52A1-
6+N2000+X1555
60 CPC5062xFD R4
#1
62 in-lbs
ACS550-PD-62A1-
6+N2000+X1555
75 CPC5077xFD R6
350 MCM
274 in-lbs
#1/0
70 in-lbs
350 MCM
360 in-lbs 3 x #3/0
250 in-lbs
ACS550-PD-77A1-
6+N2000+X1555
100 CPC5099xFD R6
ACS550-PD-99A1-
6+N2000+X1555
125 CPC5125xFD R6
300 MCM
275 in-lbs
ACS550-PD-125A1-
6+N2000+X1555
150 CPC5144xFD R6
ACS550-PD-144A1-
6+N2000+X1555
NOTE: “x” represents both NEMA 1 and NEMA 12.
TECHNICAL DATA
