FUSE SIZING/ RATINGS
600 Volt Drives
GWT AQUAVAR CPC
Voltage Phase
NEMA 1
Base
Model
Cont.
Output
Amps
Normal Duty
Horsepower
Frame
Size
Input
Current
Amps
Fuse Type³
JJS
Vendor
Part Number
575
3
CPC50031
2.7
2
R2
2.7
10
ACS550-U1-02A7-
6+N2000+X1555
CPC50041
3.9
3
R2
3.9
10
ACS550-U1-03A9-
6+N2000+X1555
CPC50061
6.1
5
R2
6.1
10
ACS550-U1-06A1-
6+N2000+X1555
CPC50091
9
7.5
R2
9
15
ACS550-U1-09A0-6
+N2000+X1555
CPC50111
11
10
R2
11
15
ACS550-U1-011A-
6+N2000+X1555
CPC50171
17
15
R2
17
25
ACS550-U1-017A-
6+N2000+X1555
CPC50221
22
20
R3
22
25
ACS550-U1-022A-
6+N2000+X1555
CPC50271
27
25
R3
27
40
ACS550-U1-027A-
6+N2000+X1555
CPC50321
32
30
R4
32
40
ACS550-U1-032A-
6+N2000+X1555
CPC50411
41
40
R4
41
50
ACS550-U1-041A-
6+N2000+X1555
CPC50521
52
50
R4
52
60
ACS550-U1-052A-
6+N2000+X1555
CPC50621
62
60
R4
62
80
ACS550-U1-062A-
6+N2000+X1555
CPC50771
77
75
R6
77
100
ACS550-U1-077A-
6+N2000+X1555
CPC50991
99
100
R6
99
150
ACS550-U1-099A-
6+N2000+X1555
CPC51251
125
125
R6
125
175
ACS550-U1-125A-
6+N2000+X1555
CPC51441
144
150
R6
144
200
ACS550-U1-144A-
6+N2000+X1555
NOTE 3: UL Class T fuses are recommended for short circuit protection. Very fast acting Bussmann* T-tron type JJS are
shown in the Aquavar CPC tables. Other manufacturers are acceptable if they meet fuse requirements.
TECHNICAL DATA
The following table provides Aquavar CPC rating information, and recommended fuse sizing for the input short
circuit protection. Branch circuit protection must be provided by the end user, contractor or distributor. Sized
according to local or applicable NEC codes.
NOTE:
THIS MANUAL SUPERCEDES PAGES 131-135 OF IM167R08.
