Page 22
22
FUSE SIZING/ RATINGS
208…240 Volt Drives
GWT AQUAVAR CPC
Voltage Phase
NEMA 1
Base
Model
Cont.
Output
Amps
Normal Duty
Horsepower
Frame
Size
Input
Current
Amps
Fuse Type³
JJN
Vendor
Part Number
230
1
CPC20171
8.5
2
R1
21.3
25
ACS550-U1-017A-
2+N2000+P918+X1555
CPC20241
12
3
R2
30.0
30
ACS550-U1-024A-
2+N2000+X1555
CPC20311
15.5
5
R2
38.8
40
ACS550-U1-031A-
2+N2000+X1555
CPC20461
23
7.5
R3
57.5
60
ACS550-U1-046A-
2+N2000+X1555
CPC20591
29.5
10
R3
73.8
80
ACS550-U1-059A-
2+N2000+X1555
CPC20881
44.0
15
R4
110.0
110
ACS550-U1-088A-
2+N2000+X1555
CPC21141
57.0
20
R4
142.5
150
ACS550-U1-114A-
2+N2000+X1555
CPC21431
71.5
25
R6
178.8
200
ACS550-U1-143A-
2+N2000+X1555
CPC21781
89.0
30
R6
222.5
225
ACS550-U1-178A-
2+N2000+X1555
CPC22211
110.5
40
R6
276.3
300
ACS550-U1-221A-
2+N2000+X1555
CPC22481
124.0
50
R6
310.0
350
ACS550-U1-248A-
2+N2000+X1555
3
CPC20121
11.8
3
R1
13.6
15
ACS550-U1-012A-
2+N2000+P918+X1555
CPC20171
16.7
5
R1
19.2
25
ACS550-U1-017A-
2+N2000+P918+X1555
CPC20241
24.2
7.5
R2
27.8
30
ACS550-U1-024A-
2+N2000+X1555
CPC20311
30.8
10
R2
35.4
40
ACS550-U1-031A-
2+N2000+X1555
CPC20461
46.2
15
R3
53.1
60
ACS550-U1-046A-
2+N2000+X1555
CPC20591
59.4
20
R3
68.3
80
ACS550-U1-059A-
2+N2000+X1555
CPC20751
74.8
25
R4
86.0
100
ACS550-U1-075A-
2+N2000+X1555
CPC20881
88.0
30
R4
101.2
110
ACS550-U1-088A-
2+N2000+X1555
CPC21141
114.0
40
R4
131.1
150
ACS550-U1-114A-
2+N2000+X1555
CPC21431
143.0
50
R6
164.5
200
ACS550-U1-143A-
2+N2000+X1555
CPC21781
178.0
60
R6
204.7
250
ACS550-U1-178A-
2+N2000+X1555
CPC22211
221.0
75
R6
254.2
300
ACS550-U1-221A-
2+N2000+X1555
CPC22481
248.0
100
R6
285.2
350
ACS550-U1-248A-
2+N2000+X1555
NOTE 3: UL Class T fuses are recommended for short circuit protection. Very fast acting Bussmann* T-tron type JJN and JJS
are shown in the Aquavar CPC tables. Other manufacturers are acceptable if they meet fuse requirements.
TECHNICAL DATA
The following table provides Aquavar CPC rating information, and recommended fuse sizing for the input short
circuit protection. Branch circuit protection must be provided by the end user, contractor or distributor. Sized
according to local or applicable NEC codes.
