Drive’s Power Connection Terminals (Supplement to Aquavar CPC User’s Manual)
The following tables show maximum wire size and required tightening torque for incomming
power and motor terminals, and grounding terminal lug information.
208…240 Volt, Terminals
208 … 240 Volt
Frame
Size
Power Wiring Data
Vendor
Part Number
HP Type Code
Circuit
Breaker
Disconnect
Switch
Motor
Terminals
Ground
Lugs
NEMA
1 & 12
1
CPC2004xFD
R1
#10
35 in-lbs
#10
7 in-lbs
#10
12 in-lbs
#10
35 in-lbs
ACS550-PD-04A6-
2+N2000+P918+X1555
2
CPC2007xFD
R1
ACS550-PD-07A5-2
+N2000+X1555
3
CPC2012xFD
R1
ACS550-PD-012A-2
+N2000+X1555
5
CPC2017xFD
R1
ACS550-PD-017A-2
+N2000+X1555
7.5
CPC2024xFD
R2
#6
45 in-lbs
#8
7 in-lbs
#6
12 in-lbs
ACS550-PD-024A-2
+N2000+X1555
10
CPC2031xFD
R2
ACS550-PD-031A-2
+N2000+X1555
15
CPC2046xFD
R3
#3
50 in-lbs
#4
18 in-lbs
#3
24 in-lbs
#3
50 in-lbs
ACS550-PD-046A-2
+N2000+X1555
20
CPC2059xFD
R3
ACS550-PD-059A-2
+N2000+X1555
25
CPC2075xFD
R4
#1
50 in-lbs
#1
55 in-lbs
#1
48 in-lbs
#2
50 in-lbs
ACS550-PD-075A-2
+N2000+X1555
30
CPC2088xFD
R4
350 MCM
274 in-lbs
#1/0 70 in-lbs
#1/0
48 in-lbs
ACS550-PD-088A-
2+N2000+X1555
40
CPC2114xFD
R4
300 MCM
275 in-lbs
ACS550-PD-114A-
2+N2000+X1555
50
CPC2143xFD
R6
350 MCM
360 in-lbs
3 x #3/0
250 in-lbs
ACS550-PD-143A-
2+N2000+X1555
60
CPC2178xFD
R6
ACS550-PD-178A-
2+N2000+X1555
75
CPC2221xFD
R6
2 x 250
MCM
274 in-lbs
2 x 250 MCM
275 in-lbs
ACS550-PD-222A-
2+N2000+X1555
100 CPC2248xFD
R6
ACS550-PD-248A-
2+N2000+X1555
NOTE: “x” represents both NEMA 1 and NEMA 12.
