Install the Line Input Wiring
Line Input Connections – Standard Input Disconnect Configurations
Connect input power to the terminals of the disconnect switch or circuit breaker. Connect the
equipment grounding conductor to the ground lug. The figure below shows the connection
points for Standard Input Disconnect configurations.
WARNING! Check the motor and motor wiring insulation before connecting the
Aquavar CPC to line power. Follow the procedure in the Aquavar CPC User’s Manual.
Before proceeding with the insulation resistance measurements, check that the Aquavar
CPC is disconnected from incoming line power. Failure to disconnect line power could
result in death or serious injury.
NOTE! For the remainder of the installation and start-up (motor and control wiring) refer to
the Aquavar CPC User’s Manual.
INSTALLATION
R1…R4
NEMA 1 & 12
Enclosures
R5, R6
NEMA 1 & 12
Enclosures
Input
Power
BP0058
R7, R8
NEMA 1 & 12
Enclosures
Input
Power
BP0057
BP0054
Dashed line is ground run.
R7 shown.
R8 similar to R7.
