Input Power Connections (Supplement to Aquavar CPC User’s Manual)
Fuses
NOTE! Although fuses listed are similar in functional characteristics to fuses listed in
the Aquavar CPC User’s Manual, physical characteristics may differ. Fuses from other
manufacturers can be used if they meet the functional characteristics of those in these
tables.
Drive input fuses are provided to disconnect the drive from power in the event that a
component fails in the drive’s power circuitry.
208…240 Volt Fuses
208 … 240 Volt
Base
Drive
Frame
Size
Drive Input Fuse Ratings
Vendor
Part Number
HP
Identification
Amps
(600V)
Bussmann
Type
1
CPC2004xFD
R1
15
KTK-R-15
ACS550-PD-04A6-
2+N2000+P918+X1555
2
CPC2007xFD
R1
15
KTK-R-15
ACS550-PD-07A5-2
+N2000+X1555
3
CPC2012xFD
R1
15
KTK-R-15
ACS550-PD-012A-2
+N2000+X1555
5
CPC2017xFD
R1
30
KTK-R-30
ACS550-PD-017A-2
+N2000+X1555
7.5
CPC2024xFD
R2
30
KTK-R-30
ACS550-PD-024A-2
+N2000+X1555
10
CPC2031xFD
R2
50
JJS-50
ACS550-PD-031A-2
+N2000+X1555
15
CPC2046xFD
R3
80
JJS-80
ACS550-PD-046A-2
+N2000+X1555
20
CPC2059xFD
R3
80
JJS-80
ACS550-PD-059A-2
+N2000+X1555
25
CPC2075xFD
R4
100
JJS-100
ACS550-PD-075A-2
+N2000+X1555
30
CPC2088xFD
R4
125
170M1368
ACS550-PD-088A-
2+N2000+X1555
40
CPC2114xFD
R4
160
170M1369
ACS550-PD-114A-
2+N2000+X1555
50
CPC2143xFD
R6
200
170M1370
ACS550-PD-143A-
2+N2000+X1555
60
CPC2178xFD
R6
250
170M1371
ACS550-PD-178A-
2+N2000+X1555
75
CPC2221xFD
R6
315
170M1372
ACS550-PD-222A-
2+N2000+X1555
100
CPC2248xFD
R6
315
170M1372
ACS550-PD-248A-
2+N2000+X1555
NOTE: “x” represents both NEMA 1 and NEMA 12 enclosures.
TECHNICAL DATA
