TABLE 2-3. MECHANICAL DATA
ITEM DATA
Dimensions (L×W×H) 184.3Ч82.6Ч83.7 mm (7.26Ч3.25Ч3.3 in)
Device Weight* (without Mount) 0.7 kg (1.5 lbs)
Device Weight* (with Mount) 0.75 kg (1.65 lbs)
Light Suppressor Weight (#1/#2/#3) 23g (0.81oz)/ 27g (0.95oz)/ 31g (1.09oz)
Height of the CO-MR Axis above Picatinny/ Weaver Rail 37.8 mm (1.49 in)
* Without Battery
TABLE 2-4. ELECTRICAL DATA
ITEM DATA
Battery * Single AA (1.5V) or CR123A (3V)
Battery Life at 20 °C 60 hr (3V) / 30 hr (1.5V)
* Any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.7V can be used
TABLE 2-5. OPTICAL DATA
ITEM DATA
Objective Lens Focal Length 80 mm
Objective Lens F/number 1:1.67
Focus Range 10 m to infinity
Field of View 12°
Exit Pupil Diameter 21 mm
TABLE 2-6. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50 °С (-40 to 122 °F)
Storage Temperature -50 to +50 °С (-58 to 122 °F)
Illumination Required Natural night illumination (overcast starlight to
moonlight)
Immersion 10 m for 30 minutes
MIL-STD-810 Complies
TABLE 2-7. IR850 DATA
ITEM DATA
IR Emitter Type LED
Peak Wavelength 850 nm
Power 500 mW
Illumination Range Up to 500 m
Divergence 8° to 12°
Battery Single CR123А (3V)
Operational Time at 20 °C (68 °F) from 1.5 hr (Full Power) to 10 hr (1/4 Power)
Overall Dimensions with Mount 117Ч41Ч37 mm (4.6Ч1.6Ч1.5 in)
Weight (with Mount, without Battery) 102 g (3.6 oz)
Operating Temperature -30 to +50°С (-22 to 122°F)
Storage Temperature -50 to +70°С (-58 to 158°F)
Environmental Rating Water Resistant
