6
LIST OF TABLES
TABLE TITLE PAGE
2-1 System Description 12
2-2 System Data 12
2-3 Mechanical Data 13
2-4 Optical Data 13
2-5 Electrical Data 13
2-6 Environmental Data 13
2-7 IR Illuminators Data 14
2-8 Scope Mounting Systems Data 14
2-9 Cipher Standard Components 15
2-10 Optional Equipment 17
3-1 Controls and Indicators 29
3-2 Button Controls 30
3-3 IR Illuminator Controls 31
4-1 Preventive Maintenance Checks and Services 34
4-2 Operator Troubleshooting 36
A-1 Cipher Spare Parts List 39
HOW TO USE THIS MANUAL
USAGE
You must familiarize yourself with the entire manual before operating the equipment. Read the entire
maintenance checklist before performing maintenance. Follow all WARNINGS, CAUTIONS, and NOTES.
MANUAL OVERVIEW
The Manual contains sections on operating and maintaining the Cipher Digital Night Vision Clip-on
System.
Throughout this Manual, the Cipher Digital Night Vision Clip-on System will be referred to as the Cipher
or the equipment.
A List of Spare Parts is in Appendix A.
The Product Warranty Registration Card is in Appendix B.
