5
3.3 Operating Procedures 31
3.3.1 Operating the Cipher 31
3.3.2 Operating an IR Illuminator 32
3.3.3 Cipher Shut-Down 32
4. PREVENTIVE MAINTENANCE AND TROUBLESHOOTING 34
4.1 Preventive Maintenance Checks and Services 34
4.1.1 Preventive Maintenance Checks and Services (PMCS) 34
4.2 Operator Troubleshooting 36
4.3 Maintenance 37
4.3.1 General 37
4.3.2 Cleaning Procedures 37
4.3.3 Battery Removal and Replacement 37
4.4 Return Instructions 38
APPENDIX 39
A. List of Spare Parts 39
B. Product Warranty Registration Card 41
LIST OF FIGURES
FIGURE TITLE PAGE
2-1 Cipher Digital Night Vision Clip-on System 12
2-2 Cipher Standard Components 15
2-3 Optional Equipment 17
3-1 Battery Installation 19
3-2 The Cipher Fully Assembled with the Mount 20
3-3 The Cipher Mounted in Front of a Day Scope 20
3-4 Mount. Top View 21
3-5 Mount. Underside View 21
3-6 Optional FSRS System. Component Parts 22
3-7 Day Scope Mounted in FSRS System 22
3-8 The Cipher and Day Scope Mounted in FSRS System 23
3-9 The Cipher Installed on the Lens of a Day Scope 24
3-10 Scope Mounting System 24
3-11 Estimation of the SMS Turning Angle 25
3-12 Light Suppressor for a Day Scope 25
3-13 Advanced Wireless Remote Control 26
3-14 The Cipher Fully Assembled with the Platform Ring 26
3-15 Platform Ring 26
3-16 IR Illuminator 27
3-17 IR Illuminator. Battery Installation 28
3-18 The Cipher with a 3x Magnifier 28
3-19 Cipher Controls 29
3-20 Button Control Panel 30
3-10 IR Illuminator Controls 31
4-1 Remote Control. Battery Installation 38
A-1 Cipher Spare Part List 39
