7
1
INTRODUCTION
1.1 GENERAL INFORMATION
1.1.1 TYPE OF MANUAL
Operation and Maintenance (including a List of Spare Parts).
1.1.2 MODEL NUMBER AND EqUIPMENT NAME
Armasight CO-LR Night Vision Clip-On System
Armasight CO-LR MG Night Vision Clip-On System
1.1.3 PURPOSE OF EqUIPMENT
The CO-LR (Clip On - Long Range) is a night vision system intended for use in conjunction with a day-
time sight, or riflescope (here on referred to as a “day scope”). When mounted on a weapon in front
of an existing day scope, the CO-LR extends the scope’s night vision capabilities up to 1000 yards,
without affecting the boresight. Advisable day scope magnification values are 2.5 to 12X (3.5 to 8X are
optimal).
The CO-LR is compatible with most commercial and military specification day scopes or binoculars, and
fits any Picatinny MIL STD 1913 or Weaver rail via the quick-release mount.
An optional FSRS Front Scope Rail System (here on referred to as the FSRS system) makes it possible to
use the CO-LR on a weapon when utilizing a short Picatinny/ Weaver rail mount.
A long-range IR850 illuminator (here on referred to as the IR850) enables use of the CO-LR in extremely
low light conditions or total darkness. Other additional equipment, such as an infrared laser, red dot
sight, etc., may also be installed on the CO-LR top Weaver rail.
NOTE:
The CO-LR can also be installed in front of the viewfinders of various instruments to widen the
operational illumination range.
1.1.4 REPORTING EqUIPMENT IMPROVEMENT RECOMMENDATIONS
Recommendations from the user for improvements to the device are encouraged.
Mail your comments to Armasight Inc., 815 Dubuque Avenue, South San Francisco, CA 94080, USA.
Or, send an email to [email protected].
