14
TABLE 2-5. OPTICAL DATA
ITEM DATA
Objective Lens Focal Length 108 mm
Objective Lens F/number 1:1.54
Focus Range 10 m to infinity
Field of View 9°
Exit Pupil Diameter 40 mm
TABLE 2-6. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50 °С (-40 to 122 °F)
Storage Temperature -50 to +50 °С (-58 to 122 °F)
Illumination Required Natural night illumination
(overcast starlight to moonlight)
Immersion 10 m for 30 minutes
MIL-STD-810 Complies
TABLE 2-7. IR850 DATA
ITEM DATA
IR Emitter Type LED
Peak Wavelength 850 nm
Power 500 mW
Illumination Range Up to 500 m
Divergence 8° to 12°
Battery Single CR123А (3V)
Operational Time at 20 °C (68 °F) From 1.5 hr (Full Power) to 10 hr (1/4 Power)
Overall Dimensions with Mount 117Ч41Ч37mm (4.6Ч1.6Ч1.7 in)
Weight (with Mount, without Battery) 102 g (3.6 oz)
Operating Temperature -30 to +50°С (-22 to 122°F)
Storage Temperature -50 to +70°С (-58 to 158°F)
Environmental Rating Water Resistant
TABLE 2-8. FSRS SYSTEM DATA
ITEM DATA
Day Scope Fitting Diameter 34; 30; 25.4 mm
Forward Cant for Extended Range 20 MOA
Space Between Clamps 50 mm
Landing Length on Weapon Picatinny/Weaver Rail 110 mm
Dimensions (L×W×H) (414Ч56Ч97) mm / (16.3Ч2.2Ч3.82) in
Weight 0.590 kg / 1.3 lbs
