30
SEq
NO.
LOCATION ITEM TO
CHECK/SERVICE
PROCEDURE
NOT FULLY MISSION
CAPABLE IF ...
5 Battery Compart-
ment/ Cap / Battery
Adapter
Check to make sure the battery adapter is present. Check for
corrosion, cap damage or retainer breaks. Check O-ring for
cuts or damage.
Retainer is broken. Cap, O-ring or battery
adapter is damaged or missing.
6 Switch Check for operation (without battery). Switch is inoperative.
7 Lenses Inspect for cleanliness, scratches, chips or cracks. Clean as
required.
Chipped or cracked. Scratches hinder vi-
sion through the CO-LR.
8 Photoreceiver Inspect for cleanliness, scratches. Clean as required. Photoreceiver is damaged.
9 Focus Knob.
Gain Control Knob*
Check to ensure there is free rotation through full range of
travel.
Knob is inoperative.
Knob is missing
10 Advanced Wireless
Remote Control
Check for damage.
Check Velcro tape for wear. Damaged. Unit or tape is missing.
11 Light Suppressor Inspect for cuts or tears. Check ease of installation and re-
moval.
Light suppressor is torn or cut.
12 Mount Inspect for damage or corrosion, and for missing parts.
Check for proper operation.
Damaged. Some parts are missing.
Clamping device is inoperative.
13 IR850 Body, Mount Inspect for damage and missing parts. Check for proper
operation.
Damaged. Missing parts. Mount is inop-
erative.
14 IR850 Battery Cap,
Power Switch
Check O-ring for damage. Check for proper operation. O-ring is damaged or missing. Switch is
inoperative.
15 IR850 Lens Inspect for cleanliness, scratches, chips or cracks. Clean as
required. Check to ensure there is free rotation through the
full range of travel (1 turn).
Lens is chipped or cracked. Lens is stick-
ing when or too loose when turned.
16 Optional FSRS
System
Inspect for damage and missing parts. Check clamping de-
vices for proper operation.
Damaged. Missing of some parts. Clamp-
ing devices are inoperative.
OPERATIONAL CHECKS
CAUTION:
The objective lens cap has an optical filter, which allows operational testing of the CO-LR in daylight. Activate the CO-LR in daylight
only with the objective lens cap on or in dark conditions.
NOTE:
Daylight checks are described below.
17 CO-LR Switch Insert the battery. Remove the output lens cap. Close the
photoreceiver by flipping up the pivotal shutter. Turn the
switch to ON position. Look for green glow (after a slight
delay) in viewing area.
No green glow.
Open photoreceiver by flipping the pivotal shutter down.
Look through the output lens and wait about 20 seconds for
the green glow to disappear.
Green glow is present, red glow is ab-
sent.
18 Remote Control Put the unit in STB. Press and hold the remote control but-
ton. Look for the green glow in output lens. Release the but-
ton. Turn the device OFF.
Green glow is absent.
19 Focus Knob Turn to the device ON. Rotate the knob to ensure it adjusts
for focus.
Knob does not adjust for focus.
20 Gain Control Knob* Rotate the gain control knob to ensure it changes the
screen’s brightness.
Knob does not adjust the screen’s bright-
ness.
21 Viewed Image Check for flickering, flashing, bright spots, edge glow, shad-
ing, or excessive fixed-pattern noise (honeycomb).
Excessive cosmetic defects or fixed pat-
tern noise is present.
22 IR850 Insert the battery. Mount the IR850 onto the CO-LR. Turn on
the IR850. Direct the radiated beam at a wall from a distance
of about 5m. Look through the CO-LR. A square of light
should appear on the wall.
No light appears on the wall.
AFTER CHECKING PROCEDURES
23 Turn off the IR850 and CO-LR. Replace the protective cap
over the CO-LR output lens.
Remove the battery.
Return the unit and all accessories to the storage case.
* For CO-LR MG version only
TABLE 4-1. CONTINUED
